PCM-3353 AMD LX800-500 PC-104 CPU模块
2024-12-20 【PLC设备】 0人已围观
简介AMD low power LX800 500 MHz/LX600 366 MHz processor 24-bit TFT LCD interface, 18/24-bit (JEIDA format) LVDS display PC/104-plus Expansion Supports up to 4 COM ports, 4 USB ports Supports
- AMD low power LX800 500 MHz/LX600 366 MHz processor
- 24-bit TFT LCD interface, 18/24-bit (JEIDA format) LVDS display
- PC/104-plus Expansion
- Supports up to 4 COM ports, 4 USB ports
- Supports SUSIAccess and Embedded Software APIs
AMD LX800-500 PC/104+ CPU模块
规格
- Part Number
- 相关讯息
- PCM-3353F-J0A2E
- PCM-3353F-L0A2E
- CPU
- Frequency
- L2 Cache
- Chipset
- BIOS
- AMD Geode™ LX600 366 MHz
- AMD Geode™ LX800 500 MHz
- 366MHz
- 500MHz
- 128 KB
- 128 KB
- AMD CS5536
- AMD CS5536
- Award 4-Mbit
- Award 4-Mbit
- Technology
- Max. Capacity
- Socket
- DDR 333/400MHz
- DDR 333/400MHz
- 1GB
- 1GB
- 1 x 200-pin SODIMM
- 1 x 200-pin SODIMM
- Chipset
- VRAM
- LVDS
- VGA
- TTL
- Dual Display
- AMD Geode LX600
- AMD Geode LX800
- Optimized Shared Memory Architecture up to 64 MB system memory
- Optimized Shared Memory Architecture up to 64 MB system memory
- Single channel 18/24-bit (JEIDA format) LVDS up to 1600 x 1200 x 32 bpp at 60 Hz
- Single channel 18/24-bit (JEIDA format) LVDS up to 1600 x 1200 x 32 bpp at 60 Hz
- up to 1920 x 1440 x 32 bpp at 85 Hz up to 1600 x 1200 x 32 bpp at 100 Hz
- up to 1920 x 1440 x 32 bpp at 85 Hz up to 1600 x 1200 x 32 bpp at 100 Hz
- Supports up to 1600 x 1200 x 32 bpp at 60 Hz for 24-bit single channel TFT Panel
- Supports up to 1600 x 1200 x 32 bpp at 60 Hz for 24-bit single channel TFT Panel
- VGA+TTL, VGA+LVDS
- VGA+TTL, VGA+LVDS
- Speed
- Controller
- Connector
- 10/100/1000 Mbps
- 10/100/1000 Mbps
- GbE: Intel 82541PI
- GbE: Intel 82541PI
- Box Header
- Box Header
- Chipset
- Realtek ALC203 (Line-in, Line-out, Mic-in)
- Realtek ALC203 (Line-in, Line-out, Mic-in)
- Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds
- Output System reset, Programmable counter from 1 ~ 255 minutes/ seconds
- CompactFlash
- PATA
- Floppy
- CompactFlash socket (Type I)
- CompactFlash socket (Type I)
- 1 Channel
- 1 Channel
- 1, 82077AA compatible (transfer from LPT, available by custom BIOS)
- 1, 82077AA compatible (transfer from LPT, available by custom BIOS)
- USB
- Serial
- Parallel (LPT)
- SMBus
- PS/2 KB/Mouse
- GPIO
- 4 x USB2.0
- 4 x USB2.0
- 3 RS-232 from COM1/3/4, 1 RS-232/422/485 from COM2 with RS-485 auto flow control (ESD protection for RS-232: Air gap ±15 kV, Contact ±8 kV)
- 3 RS-232 from COM1/3/4, 1 RS-232/422/485 from COM2 with RS-485 auto flow control (ESD protection for RS-232: Air gap ±15 kV, Contact ±8 kV)
- 1, IEEE 1284, EPP, and ECP compatible (FDD mode supported)
- 1, IEEE 1284, EPP, and ECP compatible (FDD mode supported)
- 1
- 1
- Keyboard/Mouse
- Keyboard/Mouse
- 8-bit general purpose input/output
- 8-bit general purpose input/output
- PC/104-Plus
- 1
- 1
- Power Type
- Power Supply Voltage
- Power Consumption (Typical)
- Power Consumption(Max, test in HCT)
- Power Management
- Battery
- AT
- AT
- 5V ± 5% only to boot up (12 V is optional for LCD inverter and add on card)
- 5V ± 5% only to boot up (12 V is optional for LCD inverter and add on card)
- -
- LX800: 1.35 A @ +5 V, 0.1 A @ +12 V (7.95 Watts)
- -
- LX800: 1.51 A @ +5 V, 0.1 A @ +12 V (8.75 Watts)
- APM1.2
- APM1.2
- Lithium 3 V / 196 mAH
- Lithium 3 V / 196 mAH
- Operational Temperature
- Non-Operational Temperature
- 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 85% RH non-condensing)
- 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 85% RH non-condensing)
- -40° C ~ 85° C and 60° C @ 95% RH non-condensing
- -40° C ~ 85° C and 60° C @ 95% RH non-condensing
- Dimension (mm)
- Weight
- Total Height
- 96 x 115 mm (3.8 x 4.5)
- 96 x 115 mm (3.8 x 4.5)
- 0.574 kg (1.26 lb) (with heat-sink)
- 0.574 kg (1.26 lb) (with heat-sink)
- Top side: 11.45 mm; Bottom side: 10.6 mm
- Top side: 11.45 mm; Bottom side: 10.6 mm
